AXIST90DIlluminatorSeries
Setup
HowtodeleteaPIN
1.Whentheproductisinprogrammingmode,pressandholdtheStatusbuttonfor4seconds.
2.PresstheResetbuttonfourtimes.
Howtodisablethecontrolbuttons
Withtheremotecontrol
1.Within5minutesafteryouenteroperatingmode,pressandholdtheDisableremotecontrolsetupbuttonfor4seconds.
Withthecontrolbuttons
1.Pressandholdtheleftcontrolbuttonfor4secondsuntilthelefthandsideLEDashesred.
2.PresstheleftcontrolbuttontwicesothatthelefthandsideLEDashesamber.
3.PresstherightcontrolbuttonrepeatedlyuntiltherighthandsideLEDturnssolidred.
Note
Youcanreversethissettingwiththecontrolbuttonswithin30minutes:
1.Pressandholdtheleftcontrolbuttonfor4secondsuntilthelefthandsideLEDashesred.
2.PresstheleftcontrolbuttontwicesothatthelefthandsideLEDashesamber.
3.PresstherightcontrolbuttonrepeatedlyuntiltherighthandsideLEDturnssolidgreen.
Howtore-enablethecontrolbuttons
Ifthecontrolbuttonsaredisabled,youcanre-enablethethemtemporarily(for30minutes)orpermanently.
TemporarilywithapresetPIN
•EnterthePIN.SeeHowtoenteraPINonpage9.
TemporarilywithoutapresetPIN
•Disconnectandreconnecttheproducttopower.
PermanentlywithorwithoutapresetPIN
•Doafullreset.SeeHowtoresettofactorydefaultsettingsonpage14.
HowtocontroltheilluminatorwithanAxisnetworkcamera
Thisusecaseexplainshowto:
•connecttheilluminatortotheI/OconnectorofanAxisnetworkcamera
•setupthecameratomaketheilluminatorturnonwhenthecameradetectsmotion
ConnecttheilluminatortoanAxisnetworkcamera:
1.Sniptheendofthetelemetrywires(purpleandorange)toseparatethem.
2.Connectthepurplewiretopin1(DCground)ofthecamera’sI/Oconnector.Ifyouneedmoreinformationaboutthe
camera’sI/Oconnector,seethecamera’sUserManual.
3.Connecttheorangewiretopin4(digitaloutput)ofthecamera’sI/Oconnector.
ConguretheI/Oportinthecamera’swebpage:
