Illustration and Parts Description
15
Motor
Pulley cover hand knob
Motor yoke butterfly locking
Crank handle
Rise and fall rack
Mounting flange
Base casting
Retaining collar
Lever feed handle
Keyless chuck
Drill table
Chuck guard
LED Light switch
Chuck guard micro switch
On/Off switch
Emergency stop Button
Drill column
Lift and shift clamping handle
Extension bracket arm
Pulley drive belt cover
Quill pulley Motor pulley
Micro switch
Jockey Pulley
(Drive belt tensioning)
