Drive belt tensioning lever lock Chuck guard micro switch
LED light (A) below the drill head pivots to
direct light down onto the work table
Depth stop assembly (A), Depth stop scale (B)
and Depth stop adjustable nuts (C)
A
B
C
A
Opening the chuck guard
whilst in operation will stop
the drill insently.
Move the tensioning lever to release
or tension the drive belts
