Axminster ATDP13B - Page 25

Exploded Diagram/Parts List
25
PART
NO
DESCRIPTION QTY
1 BASE 1
2 COLUMN 1
3 RACK 1
4 HEX SCREW 1
5 BOLT 4
6 RIVET 2
7 0 SCALE 1
8 GRIPPING SLEEVE 1
9 LOCKING HANDLE 1
10 WORM 1
11 SMALL SHAFT 1
12 ROCKER 1
13 BEVEL WHEEL 1
14 COLLAR 1
15 SCREW 1
16 TABLE 1
17 LOCKING HANDLE 1
18 ARM 1
19 BOLT 1
20 PIN 1
21 ANGLE SCALE 1
22 RIVET 2
23 WRENCH 1
24 WRENCH 1
25 POWER CORD 1
26 BOLT 1
27 SIDE COVER 1
28 NUT 2
29 SPRING SEAT 1
30 SPRING 1
31 WASHER 1
32 NUT 1
33 HEX HEAD SCREW 1
34 HANDLE FOR TENSION 1
35 CHECK RING 1
36 HANDLE 2
37 INITIATIVE GUIDE ROD 1
38 DRIVEN GUIDE ROD 1
39 WASHER 12 2
40 MOTOR BASE 1
41 NUT M12 2
42 DRIVER PULLEY 1
43 BELT 1
44 BELT COVER 1
45
46 MOTOR 1
47 FLAT KEY 1
48 NUT M8 4
49 WASHER 8 4
50 BOLT 4
51 CAST BODY 1
52 IDLE PULLEY SHAFT 1
53 CHECK RING 1
54 BEARING 1
55 IDLE PULLEY 1
56 CHECK RING 1
57 BOLT 1
58 HANDLE 1
59 WASHER 1
60
61 BOLT 4
62 WASHER 4
63 BOLT M8X16 1
64 SHIFTING FORK 1
65 HEX SOCKET TACKING 1
66 HEX SOCKET TACKING 1
67 HEX SOCKET TACKING 1
68 COVER 1
69 GEAR SHAFT 1
70 HANDLE ASSEMBLY 1
71 HANDLE COVER 3
72 BOLT 1
73 BELT 1
74 SCREW 3
75 SWITCH BOX 1
76
77
78
79 BOLT 4
80 SWITCH 1
81 NUT 3
82 WASHER 1
83 DEPTH SCALE 1
84 SCALE SEAT 1
85 WASHER 1
86 BEARING 1
87 RUBBER PAD 1
88 SLEEVE 1
