Axminster ATDP13B - Page 26

Exploded Diagram/Parts List
26
89 DRIFT 1
90 BEARING 1
91 BOLT 1
92 CLAMP 1
93 MAIN SHAFT 1
94 LIVE AXLE 1
95 CHUCK 1
96
97 NUT 1
98 CIRCLIP 1
99 BEARING 1
100 SPACER SLEEVE 1
101 BEARING 1
102 SPINDLE HOUSING 1
103 DRIVEN PULLEY 1
104 NUT 1
105 NUT 1
106
107 PIN 1
108 WASHER 2
109 ANTI-VIBRATION PAD 4
110 BOLT 1
111 WASHER 1
112 NUT M6 1
113 KEY 1
114 CONNECTING SHAFT 1
115 CHECK RING 2
116 COVER 1
117 BOLT 4
118 WASHER 1
119 SCREW 1
120 NUT 1
121 WRENCH 1
122 THRUST BEARING 1
123 BOLT M6X12 1
124 WASHER 1
125 MICRO SWITCH 1
126 NUT M6 1
171 SWITCH 1
181 BOLT 1
182 WASHER 1
183 SHAFT SLEEVE 1
202 LED LIGHT 1
203 BOLT 2
204 WASHER 2
205 NUT 2
206 BOLT 2
NO DESCRIPTION QTY
2-1 BOLT M5X16 2
2-2 BASE 1
2-3 STEEL BALL 1
2-4 SHRAPNEL 1
2-5 BOLT M4X6 2
2-6 MICRO SWITCH 1
2-7 COVER PLATE 1
2-8 GUIDE SLEEVE 1
2-9 LOCKING HANDLE 1
2-10 GUIDE PILLAR 1
2-11 SLIDING BLOCK 2
2-12 BOLT 2
2-13 GUARD 1
2-14 DEAD PLATE 1
2-15 BOLT 4
2-16 CABLE GLAND 1
2-17 MOUNTING PLATE 1
2-18 BOLT 2
2-19 NUT M5 2
2-20 WASHER 5 2
