INDEX OF CONTENTS
2
EU DECLARATION OF CONFORMITY
EU Declaration of Conformity 02
What’s Included 03
Optional Accessories 03
General Instructions for 230V Machines 04
Specific Safety Instructions for Woodturning Lathes 04
Specification 05
Assembly 05-06-07
Optional Bed Extension 08
Illustration and Parts Description 09-10
Operating Instructions 11-12-13
Removing the Faceplate 13
Removing Drive/Live Centres 14
Maintenance 14
Exploded Diagrams/Lists 15-16-17
Wiring Diagram 18
Notes 19
Cert No: MC1218DA
Axminster Tool Centre Ltd
Axminster Devon
EX13 5PH UK
axminstertools.com
Type Woodturning Lathe
Model AW305WL
conforms to the machinery example for which the
EC Type-Examination Certificate No AM50361061, AE501701975, AM 50380718
has been issued by Laizhou Chunlin Machinery Co., Ltd
at: No. 269 Baoshi Road, Wenfeng Street, Laizhou City, Shandong 261400 China
and complies with the relevant essential health and safety requirements.
2006/42/EC
2006/95/EC
06/42/EC - Annex I/05.2006
EN 61029-1:2009+A11
EN 61000-3-2:2006
declares that the machinery described:-
This machine complies with the following directives:
EU Declaration of Conformity
EN 55014-1:2006
EN 55014-2:1997+A1+A2
EN 61000-3-3:2008
EN 62841-1:2015
EN ISO 12100:2010
Signed
Andrew Parkhouse
Operations Director
Date: 12/06/2017
Fully read manual
and safety instructions
before use
Eye protection
should be worn
Ear protection
should be worn
HAZARD
Motor gets hot
Dust mask
should be worn
The symbols below advise the correct safety procedures when using this machine.
