Parts Index...
Model Number: HM-TS200
1 off Basic Table Saw (with Saw Blade & Riving Knife fitted) A
2 off Sliding Carriage Supporting Arms B
1 off Push Stick B1
1 off Mitre Fence Steel Bar B2
1 off Saw Guard Steel Mesh B3
1 off Work Clamp Assembly C
1 off Sliding Carriage Table D
1 off Mitre Fence E
2 off Operating Wheel Handles F
1 off Mitre Fence Clamping Knob G
1 off 30mm Hose Support Bracket H
1 off Dust Extraction Moulding Support Bracket I
1 off 4mm, 3mm Allen Keys
1 off 10-13mm, 13-15mm & 17-19 Spanners J
2 off Screwdrivers
4 off M6 x 30 Hex Bolts
4 off M6 x 46 Countersunk Heads & Nuts
4 off M6 x 16 Hex Bolts & Nuts K
2 off Carriage Arm End Stops
1 off 100mm Dust Extraction Moulding with Inlets 50/30mm L
1 off Flip Over Stop M
1 off Fence Clamp Assembly N
1 off Work Clamp Block O
1 off Connecting Block O
4 off Leg ‘A’ Frames P
4 off Long Struts Q
4 off Short Struts R
4 off Rubber Feet S
Kit Order No’s.
DescriptionQuantity
950650,718641
700060
950650,718641
950650,718641
950650,718641
950650,718641
700060
950650,718641
950650,718641
950650,718641
718641
718641
718641,700060
950650, 718641
950650,718641
950650,718641
950650,718641
950650 ,718641
700060,718641
700059,718641
700059,718641
700059,718641
700059,718641
