56
3-24 Codabar
Read:
Format
Start character
Data digits (variable)
Check digit (optional)
End character
Check digit verification: The check digit is made as the sum module 16 of the numerical values of all
data digits.
Check digit transmission: By setting Enable, check digit will be transmitted.
Max./Min. code length: Refer to Max./Min. code length of 3-20 Code 39.
Code ID setting: Refer to Code ID setting of 3-15 UPC-A.
Insertion group selection: Refer to Insertion group selection of 3-15 UPC-A.
Start/End type: Codabar has four pairs of Start/End pattern; you may select one pair to match your
application.
Start/End transmission: Refer to Start/End transmission of 3-20 Code 39.
Start/End character equality: By setting Enable, the start and end character of a Codabar barcode
must be the same.
