12
The V-Delay setting gives a delay in addition to the reference
timing. For example, if V-Delay is set to 10 TV lines, the output
signal will be delayed by the reference timing + 10 TV lines. The
signal is delayed (advanced) with respect to the phase of the
reference signal.
In 625/50 the adjustment range of V-Delay is 0-624 lines (one TV
frame).
In 525/60 the adjustment range is 0-524 lines (one TV frame).
The default setting is 0 lines.
The delay of the card is indicated by the tracking pulse on the
BNC output. This can be used, for example, to track an audio
delay.
VI-sel
With this setting you can choose which Vertical Interval you
want to put into the processed signal, or to blanking. Settings are:
CVBS or Blank. Default is CVBS.
Remove-Setup
Remove-setup enables setup (Black Level) of NTSC signals
to be removed. The settings of Remove-setup are On and
Off. The default setting is On.
Hue
Adjusts the hue. Can be set between -90 dgrs and 90 dgrs.
Chroma-Enhanc
The Chroma-Enhanc setting item enables the improvement of
the Chrominance signal being processed by increasing the edge
steepness of the chroma signal. The settings of Chroma-
Enhanc are On and Off. The default setting is Off.
Freeze
Freeze enables the capture of one Video Field or Frame
(depending on the setting of Frz-mode) when it is set to On.
Freeze can be set On or Off. The default setting is Off.
Frz-Mode
Frz-mode gives the choice of storing a complete Video Frame
or Field (double written) for the above Freeze Menu and the
external freeze input. The settings of Frz-mode are Field
and Frame. The default setting is Field.
Panic Frz
Panic-Frz enables the capture of the last video information
when the input signal is lost. Panic freeze always uses Field mode
irrespective of the settings of the Freeze-mode menu item.
The settings of Panic-Frz are On or Off. The default setting
