13
is On.
Ext-Frz
Ext-Freeze enables the external freeze input. GPI contact
closure J9 of the BPL01. The settings of Ext-Freeze are
Disabled and Enabled. The default setting is Disabled.
Y-Gain
Y-Gain controls the Luminance gain of the built-in processing
amplifier. The control range is between 0% and 150%.The default
setting is 100%.
C-Gain
Cb-Gain controls the Colour Difference gain of the built-in
processing amplifier. The control range is between 0% and 150%.
The default setting is 100%.
Y-Black
This item controls the Luminance black level adjustment between
-
128……..+127bits The black level can be aligned by +/–
100mV(analog video). The default setting is 0.
Cb-Black
This item controls the Colour Difference (Cb) black level
adjustment.
Cr-Black
This item controls the Colour Difference (Cr) black level
adjustment.
EDH-Gen
This setting allows the user to switch the built in EDH generator
on/off. The EDH generator inserts EDH (SDI Error Detection
Handling) into the output signal.
The settings of EDH-Gen are On and Off. The default setting is
On.
VLI-Ins
The Video Line Index insertion menu enables the generation of
Video Index information. Video Index is used to trigger cascaded
equipment that process wide screen manipulation, aspect ratio
converters for example. VLI-Ins can be set On or Off. The
default setting is Off.
VLI-Data
Video Line Index data insertion recognises 16 different modes.
These modes are divided into 2 groups, 4:3 and 16:9, each group
having 8 sub-categories numbered 0-7. Valid VLI-Data ranges
are 4:3_0, 4:3_1, 4:3_2, etc., to 16:9_0, 16:9_1, 16:9_2 etc. The
default setting is 4:3_0.
