14
Emb-Mode
Emb-Mode enables additional audio channels to be appended
added to the existing audio-groups in the ancillary data space of
the SDI stream Emb-Mode has three settings, Off, Append,
and Overwrite. The default setting is Off.
In Overwrite mode all existing audio groups will be
overwritten and the processes group is inserted.
In Append mode additional audio channels will be added.
In order to blank the ancillary data space of the SDI stream, set
Emb-Mode to Overwrite and set Emb-Sel to Off (see
below).
Emb-A-Sel
Emb-A-Sel determines which of the four groups of audio
available on the Synapse bus will be embedded by embedder A of
the ASV12 into the SDI stream. The settings of Emb-A-Sel are
Off, Group_1, Group_2, Group_3, Group_4. The default
setting is Off.
Emb-B-Sel
Emb-B-Sel determines which of the four groups of audio
available on the Synapse bus will be embedded by embedder B of
the ASV12 into the SDI stream. The settings of Emb-B-Sel are
Off, Group_1, Group_2, Group_3, Group_4. The default
setting is Off.
Emb-A1/2
Emb-A1/2 determines which audio channels are embedded by
channels 1 and 2 of embedder A. The available settings are,
AddOn_A1/2, AddOn_A3/4, AddOn_B1/2, AddOn_B3/4,
AddOn_C1/2, AddOn_C3/4 , AddOn_D1/2 , AddOn_D3/4.
The default setting of Emb-A1/2 is AddOn_A1/2.
Emb-A3/4
Emb-A3/4 determines which audio channels are embedded by
channels 3 and 4 of embedder A. The available settings are,
AddOn_A1/2, AddOn_A3/4, AddOn_B1/2, AddOn_B3/4,
AddOn_C1/2, AddOn_C3/4 , AddOn_D1/2 , AddOn_D3/4.
The default setting of Emb-A3/4 is AddOn_A3/4.
Emb-B1/2
Emb-B1/2 determines which audio channels are embedded by
channels 1 and 2 of embedder B. The available settings are,
AddOn_A1/2, AddOn_A3/4, AddOn_B1/2, AddOn_B3/4,
AddOn_C1/2, AddOn_C3/4 , AddOn_D1/2 , AddOn_D3/4.
The default setting of Emb-B1/2 is AddOn_B1/2.
