Introduction
Axon Signal Vehicle is part of a communications platform that, when certain hardware is
activated, transmits a message recognizable by Axon Signal compatible equipment. For
example, when the vehicle light bar is activated, Axon Signal Vehicle can signal all properly
equipped Axon systems within range to begin recording.
Axon systems that work with Axon Signal Vehicle include the Axon Body 2 camera, Axon
Flex 2 system, Axon Fleet 2 system, and all later versions.
Additional reading
If Axon Signal Vehicle is part of an Axon Fleet installation, refer to the appropriate Axon Fleet
Installation Manual for addition information and guidance.
See the Evidence.com User and Administrator Guide for information on
Signal configuration
and
Axon Body Camera Settings
for use with Axon Signal products.
Specifications
Secure Bluetooth transmission 30 seconds
Range of alerted cameras 30+ ft. (9.1+)
Operation input voltage 5.0 VDC – 14.4 VDC
Ignition enable voltage 3.6 VDC – 14.4 VDC
Trigger input voltage 3.6 VDC – 14.4 VDC
Stand-by current
- Ignition on
25 mA (typ)
- Ignition off
25 µA (typ)
Trigger input timing (positions J2-5 thru J2-10)
- Low to high transition 200 ms
- High to low transition 200 ms
Trigger input timing (positions J2-11 thru J2-12)
- Low to high transition 200 ms
- High to low transition 2.5 s*
Signal Vehicle User and Installation Guide
Axon Enterprise, Inc. 1
