* This feature is intended to reduce the likelihood of nuisance videos from extraneous triggers caused by some
progressive slide switch control modules. These controllers can cause the input voltage of Axon Signal Vehicle to drop
below 3.6 VDC when transitioning between switch positions.
Pinout table
J2 Position Description
1 Power +12VDC (fuse @ 1A)
2 Ground
3 Ignition enable
4 Auxiliary enable
5–10 Trigger Input
11–12 Trigger input, delayed turn-off
Signal Vehicle User and Installation Guide
Axon Enterprise, Inc. 2
