维修手册
专案名称：
Axpert Max 7200-48
专案编号：
P1911061
修订版次：
00
PAGE
V-RDP-004-73 A
2.3 Test step
After replacing all defected components, testing steps can be used to confirm the repair
result and the reliability of the Inverter.
Set up the testing system as below:
3. Checking and measuring guide
3.1 Check the battery side components on MAIN board
Fuse and capacitors
For Axpert Max-7200 FUCE
