Axxess AXSWC-RF User Manual

2
TABLE OF CONTENTS PREFACE
Preface ......................................................................................................................................................2
Overview
– Introduction to the AXSWC-RF Interface and Wiring Harness .......................................................2
– Mounting the AXSWC-RF Transmitter ..............................................................................................3
AXSWC-RF Installation
– Connections to be Made ...................................................................................................................4
- Setting up the AXSWC-RF ...............................................................................................................5
– Programming ....................................................................................................................................5
– Remapping the SWC (steering wheel control) Buttons .............................................................5-6
- Button Assignment Legend............................................................................................................6
– Changing Radio Type .....................................................................................................................6-7
- Radio Legend ...................................................................................................................................7
– Dual Assignment ............................................................................................................................7-8
- Dual Assignment Legend ...............................................................................................................8
AXSWC-RF Troubleshooting ................................................................................................................8-9
– LED Feedback .....................................................................................................................................9
What you need to know before you begin
1. Be sure that the radio you are installing is steering wheel control compatible. Additionally,
refer to the Radio Legend and your radio’s installation manual.
2. Update the AXSWC-RF to the latest software.
Note: To update the AXSWC-RF, go to axxessinterfaces.com and download the Axxess Updater.
Introduction to the AXSWC-RF Interface and Wiring Harness
On top of the AXSWC-RF interface there are three points of interest:
• 1) Programming LED • 2) Reset button • 3) Update port cover (slide to open)
Update Port Cover Reset Button Programming LED
AXUSB-CBL
OVERVIEW
Continued on next page

Axxess AXSWC-RF Specifications

General

Brand	Axxess
Model	AXSWC-RF
Category	Transmitter
Language	English
