6
Button Assignment Legend
1. Volume Up
2. Volume Down
3. Seek Up/Next
4. Seek Down/Previous
5. Mode/Source
6. Mute
7. Preset Up
8. Preset Down
9. Power
10. Band
11. Play/Enter
12. PTT (Push to Talk)*
13. On-Hook
14. Off-Hook
15. Fan Up
16. Fan Down
17. Temp Up
18. Temp Down
* Update:
Some newer radios use this command to activate Android/Apple voice commands.
Contact your radio vendor to see if your radios is applicable for this new feature.
Note:
Not all radios will have all of these commands. Please refer to the radio owner’s manual or
contact the radio vendor directly for specific commands recognized by that particular radio.
1.
Refer to the Radio Legend to know which radio number you would like to have programmed
.
2. After 3 seconds of turning the key on, press and hold Volume Down on the AXSWC-RF until
the LED on the AXSWC-RF interface goes solid.
3. Release Volume Down and the LED will go off, indicating that you are in the Changing Radio
Type mode.
4. Press and hold Volume Up until the LED goes solid, then release. Repeat this step for the
desired radio number you have selected.
5. Once the desired radio number has been selected, press and release Volume Down on the
AXSWC-RF; the LED will then go solid. The LED will remain on for approximately 3 seconds
while it stores the new radio information.
6.
Once the LED goes off the Changing Radio Type mode will end. You can now test the AXSWC-RF.
Note:
If at any time the user fails to press any button for a period longer than 10 seconds this
process will abort.
Continued on the next page
REMAPPING THE SWC BUTTONS (CONT) CHANGING RADIO TYPE
