7
REV. 1/21/2020 INSTAXSWC-RF
CHANGING RADIO TYPE (CONT) DUAL ASSIGNMENT INSTRUCTIONS
Radio Legend
1. Eclipse (Type 1)
2. Kenwood
3. Clarion (Type 1)
4. Sony and Dual
5. JVC
6. Pioneer and Jensen
7. Alpine
8. Visteon
9. Valor
10. Clarion (Type 2)
11. Metra OE
12. Eclipse (Type 2)
13. LG
14. Parrot*
15. XITE
* AXSWCH-PAR is required (sold separately) and the radio must be updated to rev. 2.1.4 or
higher. Additionally, the AXSWC-RF must be updated to the most recent software available.
Note: If you have a Clarion radio and the AXSWC-RF did not work try the other Clarion radio
type, same for the Eclipse
Note:
Seek Up and Seek Down are already set to Preset Up and Preset Down for a long button press.
1. Turn on the ignition but do not start the vehicle.
2. Press and hold down the AXSWC-RF button, that you want to assign a long press function to,
for about 10 seconds until the LED on the AXSWC-RF interface rapidly flashes. At this point
release the button and the LED will go solid.
3. Press and release Volume Up the number of times corresponding to the new button number
selected. The LED will blink rapidly when Volume Up is pressed and back to solid when
released. Then go to the next step when Volume Up has been pressed the desired number
of times.
Caution:
If more than 10 seconds elapses between a Volume Up press, this procedure will
abort, and the LED will go off.
4. To store the long press button in memory, press the button that you assigned a long press
button to (the button held down in Step 1). The LED will now go off indicating it has been
stored.
Tip:
These steps must be repeated for each button you would like to assign dual purpose
action to.
To reset a button back to its original use, repeat Step 1 and then press Volume Down. The LED will
go off and the long press mapping for the button will be erased.
