CHTO-01
2
Applications
CHRYSLER
300 2005-2007
Aspen 2007
DODGE
Caliber 2007-2008
Charger 2006-2007
Dakota 2005-2007
Durango 2004-2007
Magnum 2005-2007
Ram1500 2006-2008
Ram2500/3500 2006-2009
JEEP
Commander 2006-2007
Compass 2007-2008
GrandCherokee 2005-2007
Patriot 2007-2008
MITSUBISHI
Raider 2006-2007
From the 16-pin harness
• Connectthe(2)Redwirestotheignition/accessorywireoftheaftermarketradio.
• ConnecttheOrange/Whitewiretotheilluminationwireoftheaftermarketradio.Iftheaftermarketradio
doesnothaveanilluminationwire,tapeofftheOrange/Whitewire.
• ConnecttheBlue/Whitewiretotheampturnonwireoftheaftermarketradio.
• TapeuptheBrownwire.Itwillnotbeusedinthisapplication.
For vehicles with built-in navigation (only), make the following connections:
• ConnecttheLight Green wiretotheparkingbrakewireoftheaftermarketnavigationradio.
• Connectthe Blue/Pink wiretotheVSSorspeedsensewireoftheaftermarketnavigationradio.
• Connectthe Green/Purplewiretothereversewireoftheaftermarketnavigationradio.
Only make the following connections if the vehicle is amplified:
• ConnecttheWhitewiretotheleftfrontpositivespeakeroutputoftheaftermarketradio.
• ConnecttheWhite/Black wiretotheleftfrontnegativespeakeroutputoftheaftermarketradio.
• ConnecttheGraywiretotherightfrontpositivespeakeroutputoftheaftermarketradio.
• ConnecttheGray/Black wiretotherightfrontnegativespeakeroutputoftheaftermarketradio.
Continued on next page
Connections to be made
