LIST OF M
AIN
PART
1
C
ylinder cover 14 Throttle trigger
2 Mu
ffler cover
15
“P” Handle
3
Sp
ark plug 16 Adapter
4 Star
ter
17
Knob
5 Bubb
le
Prim
er
18 T
ube
6 F
uel tank cap
19
Trimmer head
7 Ch
oke lever 20
Cuttin
g attachment guard
8 Fu
el tank
21
Strap
9
Sus
pension
po
int 22 Socket spanner
10
Throttle trigger cord
23
Fuel mixture container
11 Handle
12 Throttle trigger lockout
25
4mm Allen keys
13
Engine switch 26 Air filter cover
88 89
GB
TE
CHNICAL SPECIFICATIONS
Mode
l PRT2643B1
Equipment
mobility
hand-he
l
d
Un
it mass (empty tanks without cutting
attachment)
4,8 kg
Volumes of
fuel tank
500 cm³(
0,5l)
Engi
ne model TE26FA
Engine t
y
pe
Wind-c
o
oling, 2-stroke
Fuel
type unleaded petrol, octane > 90
Engine displace
ment
26 cm
3
Ma
x engine speed for grass trimmer
7500 min
-1
Ma
x g
rass trimmer head rotational speed
12000 min
-1
Cutt
ing diameter Grass trimmer : 430 mm
Spool for gra
ss trimmer line
Mo
del : EA01GT.63.03
Ø 2,0 mm / 4
m
Engine idli
ng speed
3200±200 min
-1
Clut
ch engagement speed
4500
m
in
-1
Maxi
mum engine performance 0,75 kW
Fu
el ratio
40:1
Vibration le
vels for idling and racing handle: 7,9 m/s² , K=3,2m/s²
Sound pre
ssure level: L
pA
Lp
A, av = 103dB(A), K=3 dB(A)
Sound pow
er level: L
wA
LwA, av= 110dB(A), K=3 dB(A)
Ty
pe of carburetor
Walb
ro
Type o
f spark plug TORCH/ L8RTC
Noi
se
Infor
ma
t
ion
Measured soun
d values determined according to ISO 11806-1:2011.
The noise figures quoted are emission levels and are not necessarily safe working
levels. Whilst there is a correlation between the emission and exposure levels, this
cannot be used reliably to determine whether or not further precautions are required.
Factors that influence the actual level of exposure of work-force include the
characteristics of the work room, the other sources of noise, etc. i.e. the number of
machines and other adjacent processes, and the length of time for which an operator
is exposed to the noise. Also the permissible exposure level can vary from country.
This information, however, will enable the user of the machine to make a better
