142.5mm 142.5mm
50 | 51
GB
FILLING THE TANK
Place the air cooler on a level ground and follow the steps below:
door
holder
Take out the water pump frame when the tank was pulling out around 3/4, and
then remove the tank completely.
Fill the tank with clean water. Note: Do not add water excess the maximum
water level.
Put the water tank into the main body around 1/4, then fix the pump frame in
the correct position of the tank and push the tank into the main body completely,
and then fasten the door holder.
1)
2)
3)
Notice: This machine is equipped with two ice boxes. If you need to use it,
refrigerate it first, after that, put it into the water tank for Cooler function (The
top cover of machine also can put one ice box). With ice box, the wind would be
more cooler. Do not open the ice box to avoid eating.
Pay attention to the tank water level can not exceed the “MAX”indicator scale
when adding water; The total water level of the water tank should not be lower
than “MIN” indicating scale when using the COOLER function.
ice box
COOLER: Before acting this function, be sure to fill enough water into the lower
water tank.
Press this button and the water pump starts running. The water circulates from the
cooler master to allow warm air to be converted to cool air and cooler down the
temperature effectively. If you have used “cooler” function, when you stop the
product, the fan will be continue working for 5min to dry the cooler master; Press
the “Off” button twice, the product will be forced to stopped.
** For better cooling effect, ice box or ice is recommended to be put at the upper
water tank.
There is water shortage warning system, if the water is not enough, the COOLER
function will be automatically stopped, and 3 beeps warning sound will be heard,
and display of cooler will be blinking.
Perfume 2 setting
Perfume 1 setting
Off
Input / Replace ice box at the top water tank
1) Slightly push the edge of the display panel to open the top water tank.
2) Put ice or ice box into the top water tank.
3) Push the edge again to close the opening.
PERFUME: Press the button in the middle and open the Perfume box, put the
sachet inside; switch the button to the middle side for 1 setting as show from
above picture, indicating light on; switch the button to the left side for 2 setting,
indicating light on; switch to the rightmost side, Perfume function off.
Push
to close
Push to
open
Ice storage box
Perfume storage
box
Push
to
close
Push to
open
