1 Control panel upper housing 26 PCB3
2 PCB1 27 Motor
3 Control panel lower housing 28 Motor eccentric sleeve
4 Self-lock switch 29 Capacitor
5 Sync motor 30 Ion
6 Eccentric sleeve 31 Upper wind tunnel
7 Aroma box bracket 32 Upper cylinder
8 Upper housing 33 Lower wind tunnel
9 Aroma box setting key 34 Double shaft motor
10 PCB2 35 Motor bracket
11 Aroma box panel 36 Upper wind tunnel
12 Aroma box 37 Lower cylinder
13 Display panel 38 Lower wind tunnel
14 Front housing 39 Silicon tube
15 Vertical fence 40 Water curtain frame
16 Sync motor connecting bar 41 Water curtain
17 Vertical fence connecting bar 42 Water curtain shelf
18 Horizontal fence 43 Filter
19 Horizontal fence connecting sleeve 44 Power cord
20 Motor connecting bar 45 Fasten board
21 Air outlet frame 46 Door buckle washer
22 Small fan motor 47 Door buckle
23 Motor bracket 48 Power cord winding hook
24 Fan motor bracket 49 Motor bracket
25 Grill 50 Silicon tube
NO DESCRIPTION NO DESCRIPTION
51 Ice box 59 Water tank
52 Partition board 60 Base
53 Filter sponge 61 Wheel
54 Water tank frame 62 Handle
55 Pump 63 Handle base
56 Bobber switch 64 Remote control
57 Press plate 65 Left housing
58 Pump bracket 66 Right housing
