4- Once the housing for the strike plate has been made in the
frame, drill the screw holes using the 4 mm drill bit for the self-ta-
pping screws for wood. In the case of metal or armoured doors,
use a ø5 metal drill bit.
BE CAREFUL: Do not exceed the depth of the door
when drilling the screws. Make sure there is no pro-
blem drilling into the door, giving yourself as much
space as necessary so as not to interfere with, for
example, a multi-point lock.
BE CAREFUL: If you have to install the lock on a METAL OR
an ARMOURED DOOR, you must use the included DIN 7981
self-tapping screws for metal with a diameter of 6.3 mm (No. 8)
and a ø5 metal drill bit.
Then, remove the paper templates to start placing the int_LOCK
