Device overview
1. Beam output
2. IR remote control receiver
3. dual bracket with tightening knobs
4. rubber feet
5. IEC C14 power input + fuse
6. IEC C14 power output
7. DMX input (3p XLR)
8. DMX output (3p XLR)
9. ventilation slots
10. microphone
11. LED display with menu buttons
Remote control functions:
BL: Blackout (on/off)
SP: Speed
: Brightness
FL: Flash (Strobe)
R: Red intensity
G: Green intensity
B: Blue intensity
W: White intensity (not available on this product)
A: Amber intensity (not available on this product)
JU: Colour jump
FA: Colour fade
AU: Auto mode
SU: Sound mode
CM+ Next Colour preset
CM- Previous colour preset
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 04-11-2015 RV Revision date + author initials:
