Ayra Compar Kit Jr. User Manual

6CH Mode:
CH Function Value
1 Master dimmer 000-255 (0-100%)
2 Strobe channel 000-005 LED on
006-255 strobe slow-fast
3 Playback colour selection 000-255 colour selection
4 Background colour selection 000-255 colour selection
5 Show selection 000-030 Open
031-080 Show 1
081-105 Show 2
106-130 Show 3
131-155 Show 4
156-180 Show 5
181-205 Show 6
206-230 Show 7
231-255 Random show
6 Playback speed 000-249 speed, slow-fast
250-255 sound controlled mode
7CH Mode:
CH Function Value
1 Master dimmer 000-255 (0-100%)
2 Strobe channel 000-005 LED on
006-255 strobe slow-fast
3 Dimmer red 000-255 (red 0-100%)
4 Dimmer green 000-255 (green 0-100%)
5 Dimmer blue 000-255 (blue 0-100%)
6 Dimmer white 000-255 (white 0-100%)
7 Colour macros 000-005 No function
006-013 Colour 1
014-021 Colour 2
022-029 Colour 3
030-037 Colour 4
038-045 Colour 5
046-053 Colour 6
054-061 Colour 7
062-069 Colour 8
070-077 Colour 9
078-085 Colour 10
086-093 Colour 11
094-101 Colour 12
102-109 Colour 13
110-117 Colour 14
118-125 Colour 15
126-190 Colour jump, slow-fast
191 No function
192-255 Colour fade, slow-fast
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Ayra Compar Kit Jr. Specifications

Power

power output	max. 2000 W
supply voltage	100 - 240V AC, 50/60 Hz
nominal power consumption	33 W

Operating Environment

nominal operating temperature	0 to 40°C
fuse	F3AL250V
DMX control channels	4, 6, 7 or 18 channels

Light Output

red light output	790 lux @ 1m
green light output	1350 lux @ 1m
blue light output	1900 lux @ 1m

Weight and Dimensions

dimensions	606 x 97 x 214 mm
weight	3.1 kg
projection angle	33°
