Ayra Compar Kit Jr. User Manual

Operation Guidelines
1. Light output
2. DMX output via 3-pin XLR
3. DMX input via 3-pin XLR
4. Microphone
5. Power input via IEC C14
6. Power output via IEC C13
7. Safety eyelet
8. LED display with menu buttons
9. 35mm stand adapter
10. mounting points for suspension bracket (bracket not included / mounting points not visible in above
image)
11. Mounting point for one small extra fixture (not included)
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -
2
5
6
7
8
1
3
4
9
10 10
11 11
11

Ayra Compar Kit Jr. Specifications

Power

power output	max. 2000 W
supply voltage	100 - 240V AC, 50/60 Hz
nominal power consumption	33 W

Operating Environment

nominal operating temperature	0 to 40°C
fuse	F3AL250V
DMX control channels	4, 6, 7 or 18 channels

Light Output

red light output	790 lux @ 1m
green light output	1350 lux @ 1m
blue light output	1900 lux @ 1m

Weight and Dimensions

dimensions	606 x 97 x 214 mm
weight	3.1 kg
projection angle	33°
