Ayra Compar Kit Jr. User Manual

Technical Specifications
Basic Features:
- Compact LED lighting set
- Electronic bar with four independently adjustable spots
- Can be installed standing or suspended
- Energy efficient LED technology
- Power sharing function for daisy-chaining
- Various operation modes
- Included IR remote control
- 4-digit menu display with various adjustable functions
Technical Specifications:
- 3x 3W RGBW LED light sources per spotlight
- Automatic, sound controlled, static, DMX and master-slave operation modes
- DMX control via 4, 6, 7 or 18 channels
- master/slave function for synchronised light shows using multiple and diverse fixtures without using DMX
- Built-in microphone for sound controlled mode with adjustable microphone sensitivity
- Built-in colour macros, colour jump and colour fade
- Adjustable status mode using colour macros and manual dimming per colour
- Fitted with 35mm stand adapter
- Power input: IEC C14 power socket
- Power output: IEC C13 power socket, max. 2000 W
- DMX input and output via 3-pin XLR
- Supply voltage: 100 - 240V AC, 50/60 Hz
- Nominal power consumption: 33 W
- Nominal operating temperature: 0 to 40°C
- Fuse: F3AL250V
- Dimensions: 606 x 97 x 214 mm
- Weight: 3.1 kg
Remote Control
- Infrared remote control
- Battery type: CR2025 (included)
Light Output:
- Red: 790 lux @ 1m
- Green: 1350 lux @ 1m
- Blue: 1900 lux @ 1m
- White: 1790 lux @ 1m
- Full on: 5970 lux @ 1m
- Projection angle: 33°
Available Accessories (sold separately):
- Bracket set for standing or suspended installation
- Replacement remote control
- Carry bag
Contact your local retailer for more information about the availability of any parts or accessories.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Ayra Compar Kit Jr. Specifications

Power

power output	max. 2000 W
supply voltage	100 - 240V AC, 50/60 Hz
nominal power consumption	33 W

Operating Environment

nominal operating temperature	0 to 40°C
fuse	F3AL250V
DMX control channels	4, 6, 7 or 18 channels

Light Output

red light output	790 lux @ 1m
green light output	1350 lux @ 1m
blue light output	1900 lux @ 1m

Weight and Dimensions

dimensions	606 x 97 x 214 mm
weight	3.1 kg
projection angle	33°
