Azbil Infilex AC Series - Main Unit Specifications; Wiring Specifications

AB-6546
6
Specifications: Model QY5100W0000 (Panel Mount Type)
Main unit specifications
Item Specification
Rated voltage 100 V AC to 240 V AC, 50 Hz/60 Hz
Allowable voltage range 85 V AC to 264 V AC
Power supply Model QY5100W0000
Power consumption 8 VA
Ambient temperature 0 °C to 50 °C
Ambient humidity 10 %RH to 85 % RH (Non-condensing)
Altitude 2000 m or lower
Rated operating
conditions
Vibration 5.9 m/s
2
or less (at 10 Hz to 150 Hz)
Ambient temperature -20 °C to 60 °C
Ambient humidity 5 %RH to 85 % RH (Non-condensing)
Vibration (for storage) 5.9 m/s
2
or less (at 10 Hz to 150 Hz)
Environmental
conditions
Transport and storage
conditions
Vibration (for transport) 9.8 m/s
2
or less (at 10 Hz to 150 Hz)
Status indication LED (Green) Power ON: Power ON, OFF: Power OFF
Transmission system RS-485
Transmission speed 4800 bps
Transmission distance 10 m
Communication DP-bus
Number of remote units to
be connected
1
Resolution 128 × 64 (dots)
Gradation 2 tones: black and white
Backlight LED backlight
Display LCD
Contrast adjustment Trimmer
Material Silicon rubber Input Key
Key names [mode], [<], [>], [→], [∧], [∨], [enter]
Weight 400 g
Material / color Modified PPE / light gray
Power M3 screw Terminal
connection
Communication (DP-bus) M3 screw (Modular connection*)
∗ Modular adaptor is pre-connected to the M3 screw terminals.
Wiring specifications
Item Wiring Wiring length Condition
Power supply JIS* IV 2.0 mm
2
or JIS CVV 2.0 mm
2
or greater ⎯ ⎯
Ground JIS IV 2.0 mm
2
or JIS CVV 2.0 mm
2
or greater ⎯ Ground resistance: 100 Ω or lower
DP-bus Model DY7210 Connector cable,
Model DY7220 Short connector cable, or
Cable compliant to EIA/TIA-568 Category 5 or above
10 m ⎯
∗JIS: Japanese Industrial Standards
Model Numbers: Model QY5100W0000 (Panel Mount Type)
Base model number Power ⎯ Description
QY5100
Operator Panel for Infilex AC / Infilex GC / Infilex GD
Panel mount type (Mounted on the door of the control panel cabinet.)
W 100 V AC to 240 V AC
0000 ⎯
Note:
Operation manual for Model QY5100W0000 (AB-6547) is available. When you order the product, request the manual if necessary.
