AB-6546
7
Specifications: Model RY5001Q0000 (Integral Type)
Main unit specifications
Item Specification
Ambient temperature 0 °C to 50 °C
Ambient humidity 10 %RH to 90 %RH (Non-condensing)
Altitude 2000 m or lower
Rated operating
conditions
Vibration When assembled with Infilex AC:
5.9 m/s
2
or less at 10 Hz to 150 Hz
When assembled with Infilex GC/Infilex GD:
3.2 m/s
2
or less at 10 Hz to 150 Hz
Ambient temperature -20 °C to 60 °C
Ambient humidity 5 %RH to 95 %RH (Non-condensing)
Vibration (for storage) When assembled with Infilex AC:
5.9 m/s
2
or less at 10 Hz to 150 Hz
When assembled with Infilex GC/Infilex GD:
3.2 m/s
2
or less at 10 Hz to 150 Hz
Environmental
conditions
Transport and
storage
conditions
Vibration (for transport) 9.8 m/s
2
or less at 10 Hz to 150 Hz
7 segment LED
4 digit × 2 lines (Upper line in green, lower line in red)
Upper line: Point number is displayed.
Lower line: Max. 6 digit number is displayed. (Upper 2 digits are
displayed first, and lower 4 digits are displayed with [∧] key.) For the
decimal number, max. 3 digits after the decimal point are displayed.
Display
LED
Dot LED for status indication [OFF], [ON], and [→] in green
[ALM] in red.
Material Silicon rubber Input
Key
Key names [MODE], [∧], [∨], [ENTER], [→]
Weight 170 g
Material / color Modified PPE / light gray
Wiring specifications
Item Wiring Wiring length Condition
Remote Controller bus Model DY7210 Connector cable,
Model DY7220 Short connector cable, or
EIA/TIA-568 Category 3 or over
50 m ⎯
Model Numbers: Model RY5001Q0000 (Integral Type)
Base model number ⎯ ⎯ Description
RY5001
Operator Panel for Infilex AC / Infilex GC / Infilex GD
Integral type (Assembled with Infilex AC / Infilex GC / Infilex GD)
Q ⎯
0000 ⎯
Note:
Operation manual for Model RY5001Q0000 (AB-6642) is available. When you order the product, request the manual if necessary.
CE Marking Conformity
This product must be installed in a panel cabinet. Besides, the product in the panel cabinet must be out of reach of
unauthorized people who are not well-trained for electric facilities.
This product complies with the following Electromagnetic Compatibility (EMC) and the Low Voltage Directive (LVD).
EMC: EN61326-1 Class A, Table 2 (For use in an industrial electromagnetic environment)
LVD: EN61010-1 Overvoltage category II
Pollution degree 2
