AB-6546
8
Dimensions: Model QY5100W0000 (Panel Mount Type)
<Main unit dimensions>
Figure 2. Main unit dimensions (mm): Model QY5100W0000
<Mounting panel cutout dimensions>
Figure 3. Mounting panel cutout dimensions (mm): Model QY5100W0000
91.8
70
91.8
91
96
96
30 or wide
r
30 or wide
r
92
+0.5
0
92
+0.5
0
