3. Coding method for model numbers:
⑥ Attachment of Pump Returning Oil
⑪ Attachment of Pressure Switch *
Nil (Oil is excluded automatically by
pressure of fog-bowl)
⑨ Air Preparation Equipment, and Others
With D04 type Filter-Regulator
integrating sol. valve, 5μm ＊
＊All models with electrical control circuit are
equipped with solid-state type (NPN type)
pressure switches at factory set.
＊EN model type corresponds to 8, 9, 0 only.
With D14 type Regulator
integrating sol. valve
With D14 type Regulator
integrating sol. valve,
& with M4000 type tar removal filter.
⑫ Setting of Operating Pressure Switch
Set of switching pressure for Operating
Pressure Switch
EN models approved by TUV ＊
＊D04 units with element of 0.3μm are available.
Consult to Azbil TA if required.
＊A supply air preparation equipment and
electrical control circuit are not available for EN
models (specified by T at the 9th digit of model
number.)
Replace with Figures *.* multiplied by 10
to setting pressure by MPa units.
⑬ Setting of Manifold Pressure Switch
Set of switching pressure for Manifold
Pressure Switch
⑩ Attachment of Electrical Control Circuit Board
and Drip Monitor
Oil Drip Monitor, or Oil
Feed Monito
Electrical
Control circuit
Replace with Figures *.* multiplied by 10
to setting pressure by MPa units.
K1.3 = for setting of 0.13±0.01MPa
With Oil Drip Monitor(NPN)
K1.5 = for setting of 0.15±0.01MPa
With Oil Drip Monitor(NPN)
With Oil Drip Monito(PNP)
⑭ Setting of Manifold Pressure Switch
＊Models with electrical control circuit can be
operated only by DC24V.
Applying other voltages are impossible.
＊Output of Drip monitor is operated by supply
voltage of DC10～30V.
＊Oil Feed Monitor can be used with supply voltege
of DC12～24V.
To Next Page
