Chapter 3. MOUNTING AND WIRING
● Accuracy and straight pipe length
• Connection with different size piping, valve or filter
Install straight pipes as needed with the lengths given in the table below.
If a device that is not listed in the table is installed either upstream or downstream,
contact the azbil Group for the length of the straight pipe section.
If reverse flow is also expected, it is necessary to have the same length of straight
pipe downstream as upstream.
Note 1: Do not connect a carbon steel pipe for pressure service (JIS G3454) or stainless steel pipe (JIS
G3459) that is larger than schedule 40. Doing so might cause a deterioration of accuracy. (If the
pipe schedule number is larger, the inner pipe diameter is smaller, resulting in reduced accuracy.)
Pipe or connected device Location in Straight pipe section for this device
relation to For accuracy within For accuracy
the MCF specifications (±3 % FS) within ±5 % FS
MFF25S mist separator for MCF0080/0150/ Upstream 10D (Not required)
0151/0250 (Note 3)
MFF25L mist separator for MCF0400/0500 Upstream 20D (Not required)
(Note 3)
Pipe one size larger in dia. Upstream 5D (Not required)
(connected with reducer) (Note 4, 5)
MCF0080 3/8 inch
→1/4 inch
MCF0150/0151 3/4 inch
→1/2 inch Downstream (Not required) (Not required)
MCF0250 1 1/4 inch
→1 inch
MCF0400 2 inch→1 1/2 inch
Pipe one size larger in dia. Upstream 10D 5D
(connected with reducer) (Note 4, 5)
MCF0500 2 1/2 inch→2 inch
Downstream 5D 5D
Pipe one size smaller in dia. Upstream 20D 5D
(connected with enlarging pipe) (Note 4, 6)
MCF0080 1/8 inch
→1/4 inch
MCF0150/0151 3/8 inch
→1/2 inch Downstream (Not required) (Not required)
MCF0250 3/4 inch
→1 inch
MCF0400 1 1/4 inch→1 1/2 inch
Pipe more than one size smaller in dia. Upstream 25D 10D
(connected with enlarging pipe) (Note 4, 6)
MCF0500 1 1/2 inch→2 inch
Downstream 5D 5D
Single elbow Upstream 10D (Not required)
(Note 7) Downstream (Not required) (Not required)
Double elbow Upstream 10D 10D
(Note 7) Downstream (Not required) (Not required)
Ball valve (full-bore type full open) Upstream (Not required) (Not required)
(Note 8) Downstream (Not required) (Not required)
Regulator for MCF0080 Upstream 200D (Not required)
(Note 9) Downstream 10D (Not required)
Regulator for MCF0150/0151/0250/0400/ Upstream 30D (Not required)
0500 (Note 9) Downstream 5D (Not required)
Air filter Upstream 25D (Not required)
