29
Chapter 5. SETTING AND OPERATION
If the setting exceeds the upper limit for indication, the instantaneous flow rate
output will be equivalent to the upper limit for indication.
Do not set values for Event 1 instantaneous flow rate or Event 2 instantaneous
flow rate that exceed the upper limit for indication. The instantaneous flow rate
may not reach the set value, so that the event does not operate.
Device information display
Viewing the display
(1) Press and hold the [enter] key for 2 seconds or more while the instantaneous
flow rate or integrated flow is indicated on the display.
>> The MCF moves to the device information display mode, and indicates the
item and the related information alternately.
(2) To move to the next item, push []. To return to the previous item, push [].
(3) To quit the device information display mode, push the [mode] key.
>> The MCF returns to normal indication mode.
Device information
*1. The cost calculation can be changed by changing the COSt rate (COSt) setting in
the parameter setup. If the case of integrated flow countdown, cost is not indicat-
ed.
*2. If 01is selected for Integrated flow option (C12) in the function setup, the MCF
indicates a remaining reverse flow. When the flow returns to normal, this reverse
flow is subtracted.
Item Name Description
Id
_
01 Model number ID MCF0080
0
MCF0150
1
MCF0151
5
MCF0250
2
MCF0400
3
MCF0500 4
Id
_
02 Measurement range ID MCF0080 2000 (200.0L/min)
MCF0150
5000 (500.0L/min)
MCF0151
10000 (1000.0L/min)
MCF0250
3000 (3000L/min)
MCF0400
6000 (6000L/min)
MCF0500 12000 (12000L/min)
Id
_
03 Firmware version
COSt.L Cost (last digits) Cost, calculated with the flow rate-cost multiplier.
*1
COSt.H Cost (first digits)
IrE
_
.L Reverse integrated flow (last digits) The integrated flow amount at the time of reverse
IrE
_
.H Reverse integrated flow (first digits) flow.
*2
ItOt.L Total integrated flow (last digits) Total integrated flow from the time of shipment.
ItOt.H Total integrated flow (first digits) Resetting the integrated flow does not affect this total.
IPrE.L Integrated flow before resetting (last digits) The integrated flow before it was reset.
IPrE.H Integrated flow before resetting (first digits)
C02setting MCF0080 MCF0150 MCF0151 MCF0250 MCF0400 MCF0500 Notes
00: [L/min] 0 to 800 0 to 2000 0 to 4000 0 to 12000 0 to 24000 0 to 48000
01: [m
3
/h] 0 to 48.0 0 to 120.0 0 to 240.0 0 to 720.0 0 to 1440.0 0 to 2880.0
02: [m
3
/min] 0 to 0.800 0 to 2.000 0 to 4.000 0 to 12.000 0 to 24.000 0 to 48.000
03: [kg/h] 0 to 62.1 0 to 155.2 0 to 310.4 0 to 931.0 0 to 1862.0 0 to 3724.0
The upper limit
of the range
corresponds to a
flow rate of 400
%FS.
