*2: Input the model number and identifier of the replacement measurement module using the following
procedure:
(1) For SYS0 1, select the model number appropriate for the pipe size of the main path.
(2) Check the number (15 digits) shown on the label on the main flow path and register the numbers for flow
path identifiers 0 to 2. Or, before making the replacement, record in advance the settings for flow path
identifiers 0 to 2 on the previous measurement module, and register them for the new replacement
measurement module.
Note: Registering the wrong numbers for model number and flow path identifier may result in incorrect
display of the flow rate.
(3) In Ao20, the flow rate assignment for 20 mA analog output in the parameter setup (page 25), set one of
the initial values shown below, as appropriate for the model number.
Model number Pipe size SYS0 1 setting
MCF0250 1B 2
MCF0400 1 1/2B 3
MCF0500 2B 4
Body Number
00000
- XXXXX - XXXXX
Flow path identifier 0 Flow path identifier 1 Flow path identifier 2
Model number Setting value
MCF0250 03000
MCF0400 06000
MCF0500 12000
32
Chapter 5. SETTING AND OPERATION
