41
Chapter 7. SPECIFICATIONS
● MCF0250 Unit : mm
● MCF0400
Connection type and size
2-Rc1 or 2-G1 (thread depth: 19.1)
MCF cable connector
2-M4 ,Thread depth 7
(Retaining screws)
Mounting bracket
Connector (M12)
23.5
(90)
(75)
47
79.8
27
48
24
13.5
(63)
(78)
(4.5)
90
(60.5)(8)
23.5
48
mode
enter
ALEVLL/min
MCF
2-M5 ,Thread depth 7
(Retaining screws)
MCF cable connector
Connection type and size
2-Rc1 1/2 or 2-G1 1/2
(thread depth: 21.4)
Connector (M12)
30
30
(74.5)
62
100
93.8
60
34
17
61
30.5
mode
enter
ALEVLL/min
MCF
