40
■ External dimensions
● MCF0080 Unit : mm
● MCF0150/MCF0151
2-M4 ,Thread depth 7
(Retaining screws)
Mounting bracket
Connection type and size
2-Rc1/4 or 2-G1/4 (thread depth: 11)
MCF cable connector
Connector (M12)
23.5
65.8
27
48
24
13.5
(90)
(75)
47
75
(78)
(63)
(4.5)
34
15
(46.5)(8)
mode
enter
ALEVLL/min
MCF
Mounting bracket
Connection type and size
2-Rc1/2 or 2-G1/2 (thread depth: 15)
MCF cable connector
2-M4 ,Thread depth 7
(Retaining screws)
Connector (M12)
23.5
(4.5)
47
75
(8) (46.5)
34
15
(63)
(78)
65.8
27
48
24
13.5
(90)
(75)
mode
enter
ALEVLL/min
MCF
Chapter 7. SPECIFICATIONS
