Aztech WL889RT4

Aztech
WL889RT4
USER MANUAL
9
Setup Diagram
Setup DiagramSetup Diagram
Setup Diagram
Installation Setup
Installation SetupInstallation Setup
Installation Setup
1. Connect the supplied Ethernet Cable from your computer’s Ethernet port to any of the
available LAN ports at the back of WL889RT4
2. Use another Ethernet cable to connect your Broadband modem to WL889RT4’s WAN port.
3. Connect the Power adapter to the 9V DC port at the back of the WL889RT4 and plug to a
power source. Please turn on the power source before you proceed to the Internet
connection setup.
Note
NoteNote
Note
Make sure to set your computer’s IP address to automatic, to acquire IP address from the router automatically.
Internet Connection Setup
Internet Connection SetupInternet Connection Setup
Internet Connection Setup
Broadband Modem
Aztech WL889RT4
Power Adapter
Laptop
Desktop Computer
