PT-5IT SYSTEM BOARD HARDWARE SETUP
10
(D) JP13 ROM BIOS selection
Pin # Function
1-2 for +5V FLASH ROM
2-3 for +12V FLASH ROM
(E) JP2,JP3 DIMM voltage selection
Pin # Function
1-2 +5V DC
2-3 +3.3V DC (Factory default)
