PT-5IT SYSTEM BOARD AWARD BIOS SETUP
11
A. INTEGRATED PERIPHERALS
ROM PCI / ISA BIOS (2A59IXXX)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD Block Mode : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto Onboard Parallel Port : 378 / IRQ7
IDE Secondary Master PIO : Auto Parallel Port Mode : SPP
IDE Secondary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
On-Chip Primary PCI IDE : Enabled
On-Chip Secondary PCI IDE : Enabled
USB Keyboard Support : Disabled
Onboard FDD Controller : Enabled
Onboard Serial Port 1 : 3F8 / IRQ4
Onboard Serial Port 2 : 2F8 / IRQ3 ESC : Quit
 : Select Item
Onboard IR Controller : Disabled F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F7 : Load Setup Defaults
Fig. 5-8 INTEGRATED PERIPHERALS setup screen.
WARNING : The INTEGRATED PERIPHERALS in this screen are provided so that
technical professionals can modify the Chipset to suit their requirement.
If you are not a technical engineer, do not use this program !
Onboard IR Controller :
This setting determines the IR port (CN 11) function mode. Supports both HPSIR and
ASKIR.
Onboard Parallel Mode :
This setting determines the onboard parallel prot (CN 8) transmission mode. Supports
either SPP, EPP, ECP or ECP+EPP.
