DOESN’T WORK (sensor) 8 PUT THE SENSOR FRONTALLY TO THE TUBE
AXIS
(the door closes but the sensor
doesn’t work if I press it)
8 CONTROL THE CONNECTIONS ( brown +12Vdc)
(blue 0V dc ) ( black connected to the cable 7 in the
local plant)
9 THE DOOR STOPS AT THE
PHOTOCELL LEVEL AND
COMES BACK
9 REGULATE THE SLOWING DOWN LIMIT SWITCH:
IT CLOSES 10 CM BEFORE THE PHOTOCELL ( the
contact switch off the functioning )
10
THE DOOR CLOSES ONLY 50
CM AND THEN COMES BACK
10 INCREASE THE INTERVENTION TIME OF THE
ANTI-JAMMING PHOTOCELL USING THE
PROGRAMMER (PARAMETER SETTING- ANTI-
JAMMING PHOTOCELL READING)
10 LOWER THE ANTI-JAMMING PHOTOCELL
SENSOR
11
LD1 REMAINS ON( IN THE TOP
LEFT-HAND )
11 VERIFIY THE FUSE
11 THE CARD IS DAMNAGED ( replace it)
12
THE DOOR DOESN’T CLOSE
AUTOMATICALLY
12 VERIFY DIP 1 ( ON = automatic ) (OFF = manual )
12 CONTROL THE CORRECT FUNCTIONING OF THE
SAFETY COMPONENTS ( LD 7 - LD 13- LD 6 on)
13
THE DOOR WORKS BUT
SOMETIMES IT GETS STUCK
13 VERIFY THE CORRECT SETTING OF THE MOTOR
WITH THE PROGRAMMER (PARAMETER SETTING
– TYPE OF MOTOR ……KW)
(in any position)
13 CONTROL THAT THE FLASHING LIGHTS WIRES
OR THE MOTOR BRAKE WIRES ARE NOT IN THE
SAME CABLE OF THE PHOTOCELL AND LIMIT
SWITCH (interference problem) they must have their
own cable and tube ,the 230V must be separated
from 12- 24V
