13 VERIFY WITH THE TESTER THAT THE CURRENT
ISN’T LOWER THAN 220V (control when the door’s
working) if the current is lower than 220V control the
input
13 VERIFY WITH THE PROGRAMMER THAT THE BUS
VOLTAGE ISN’T LOWER THAN 300V (SYSTEM
CONDITION – BUS VOLTAGE) (control when the
door’s working) if the voltage is lower than 300V
control the input.
13 VERIFY WITH THE PRORAMMER THE MOTOR
UPTAKE (SYSTEM CONDITION- MOTOR CURRENT
with motor 0,75kw can’t be higher than 7A;with motor
1,5 kw can’t be higher than 9A, control when the
door’s working) if the door exceeds the threshold
lower the opening HZ
14
THE PHOTOCELL DOESN’T
WORK
14 CONTROL THAT IN THE VICINITY THERE AREN’T
ANY OTHER PHOTOCELLS THAT COULD CAUSE
REFLECTION (try to darken the photocells)
(the door closes but the photocell
doesn’t reverse the curtain)
14 CONTROL THAT WITH THE PHOTOCELL CABLES
THERE AREN’T ANY HIGH VOLTAGE CABLES
(motor ,motor brake, flashing lights, power line) (take
to the control board separated cables in different
pipes, separate the low voltage 12-24V from the high
voltage ≥ 100V)
14 PUT THE MINUS OF THE RECEIVER (black cable,
blue wire) ground
15
WITHOPENDOOR(locked)THE
CURTAINSLOWDOWN
15
SETTHEMOTORBRAKE(removethefancoverandcloseof
aquarterturnofthedialbrakeadjustement,thenmake
teststoreachtheoptimum)
