6. Replacement of Emitter Lamp Tube
Un-plug the power supply, before replacing the infrared emitter / tube.
1. Remove the side panel.
2. Release the radiating panel / reflector.
3. Disconnect the two leads to the emitter /lamp.
4. Remove the protective grill on the front of the cassette.
5. Take out the defective emitter and fit the new emitter after checking that the part you
purchased is correct. Ensure that you attach the wires correctly.
6. Install the protective grill, radiating panel and the side panel.
Use a piece of soft cloth or cotton to clean the reflector panel and the emitter with alcohol.
Cleaning must be conducted after the machine is disconnected from the power source and
cooled down if necessary. Do not restart the equipment until all solvent / cleaning fluid
residue has evaporated. 15 minutes advised as the evaporation time.
