Test Procedure
34
DHV0078 b2 EN
© b2 electronic GmbH
Step
Procedure (withstand test)
S1 Connect all earthing cables
• Connect earthing cable to the HVA earthing connector
• Connect earthing cable to the DUT ground
S2 Connect power supply cable
• Connect the power supply cable to the HVA power supply plug
S3 Connect HV test lead
• Screw the HV test lead into the HVA HV output connector
• Connect the HV cable shield to earth (if clamp is available)
• Connect other end of HV test lead (clamp including screen protector)
to the DUT
S4 Verify connections
• Check that all cables are attached securely.
S5 Configure interlock plug
• Verify that the HV interlock adapter is connected
If operating with remote controls (optional):
• Connect external lamps or remote switches
• Refer to 3.4 – Shipment Content for connection diagram and material
requirements
S6
Configure communication port
For USB data transfer mode:
• Connect the USB flash adapter
• Insert USB stick
Otherwise:
Verify that RS232 cable is not connected to the HVA!
S7
Turn “ON” HVA main switch
S8
Turn key switch to the “ON” position
S9
The HVA system automatically boots.
• Start-up default screen appears
”Main Menu” or “Manual Mode” screen
See 4.3 – Instrument Setup
Select appropriate option from default screen and proceed to appropriate section
for further instructions:
• See 5.2 – Manual Test Mode or
See 5.3 – Automatic Test Mode
