6 Reporting Procedure
Report type
The HVA can generate two report types: A “Basic” report with limited information or
a more complete “Extended” report. The type of report generated corresponds to
the entry selected in “Instrument Settings”. Before testing, verify that the desired
type is set!
See 4.3: Instrument Setup
Report information
Basic
Extended
DUT type
 
Voltage rating
 
(Cable) insulation type
 
Report title
 
Phase name

Company name

Region name

Station name

Line length

Size of DUT

Manufacturer

Work order

Operator name

Report activation
Reporting is possible in both the test modes. To generate a report in the manual
mode, the procedure must begin with “Start a New Test” from the main menu. See
5.2 – Manual Test Mode
Start a New Test
Do you want to
store a report?
Yes No
MAIN
