Configuring auto test sequence – detailed steps
Steps AS1-AS15 describe how to configure a test sequence.
Step Procedure (configure automatic sequence) Example
AS1:
EDIT or NEW?
The “Edit Auto Test Seq.” Menu displays the sequences
already stored in memory.
• To modify an existing program, highlight the
corresponding program from the list and select the
“EDIT” option on the bottom of the screen
• To create a new program, select the “NEW” option
on the bottom of the screen
AS2:
DUT
Select one of the following DUT types:
• Cable
• Motor
• Generator
• Transformer
• Switchgear
• Other
• Vacuum bottle
AS3:
Voltage rating
Specify the voltage rating of the DUT.
This is a characteristic of the DUT and does NOT
refer to the test voltage!
To increase/decrease the voltage rating, rotate
navigation knob
To accept value, push in knob.
AS4:
(Cables only)
Insulation
Select one of the following cable insulation types:
• XLPE
• PILC
• EPR
• PE
• PVC
• HYBRID
(combination of types)
• OTH. (other)
AS5:
Test purpose
Select aim of test from one the following:
• Acceptance
• Maintenance
• Diagnostic
AS6:
Waveform
Select one of the following output modes:
• Sine wave
• Square wave
• DC+
• DC-
• Vacuum bottle test
Edit Auto Test Seq.
3.0kV Maint. C. HYBR (T)
BACK SELECT EDIT DEL NEW
New Auto Test Seq.
What is the
Device under Test?
Cable
CANCEL NEXT
New Auto Test Seq.
Cable
What is the
Voltage Rating of DUT?
1.0kV
CANCEL PREV NEXT
New Auto Test Seq.
1.0kV Cable
What type of
Insulation?
XLPE
CANCEL PREV NEXT
New Auto Test Seq.
1.0kV Cable XPLE
Test Function?
Maintenance
CANCEL PREV NEXT
New Auto Test Seq.
1.0kV Cable XPLE
Maintenance
Waveform for Test?
Sine
CANCEL PREV NEXT
