5-POINT HARNESS SYSTEM
Adjusting the Harness Height
It is recommended that the shoulder strap should be under the shoulder strap
bar for weight from 9-13kg children, and should be above the shoulder strap
bar for weight above 13kg.
1. Pull the reclining adjusting handle to the most reclined 4 position (F1.)
2. Release the installation bar lock (F2) on the top left side shell and remove
the long axis, pull and hold the shell forward.
3. Unhook the shoulder pad straps from shoulder pad connector (F3).
Unhook the shoulder harness straps from yoke (F4).
4. Pull out the shoulder straps and harness and insert them with a suitable
height of the shoulder strap, hook the connector and Yoke. Return the
shell to its original position and re-insert the long axis and lock it.
long axis
long axis
