Baby Lock Evolution BLE8W-2 - 3-Thread Overlock - Narrow Hem

O
V
E
R
L
O
C
K
S
T
I
T
C
H
E
S
E
X
P
R
E
S
S
31
3-Thread Overlock - Narrow Hem
A
B
Narrow Hem is an attractive finish for light to medium weight fabrics.
Remove the O-1 needle and needle thread completely from the
machine. Clear the stitch fingers. Turn the stitch length adjusting dial
clockwise to the rolled hem range. Set the length at "1" (fig. A) and the
stitch width at 3.0 (fig. B) for a smooth decorative finish.
Move the stitch selector lever to "C".
For the O-2 needle 3-thread narrow hem, follow the suggested settings
and the threading diagram below.
NEEDLES
O-2
LENGTH
0.75 - 4.0R
WIDTH
3.0
STITCH
SELECTOR
C
WAVE
SELECTOR
OVERLOCK
〈 〉
