Babyletto Mercer Crib User Manual

Attach 4 post brackets (E) to each pair of
left and right posts (G+H) using 3 Phillips
head screws (S).
STEP 1.
STEP 2.
page 3
HARDWARE
ZZ. Allen wrench
Tools Needed
(not included)
Phillips
screwdriver
V. 3/4” Allen
head bolt (4)
T. 1 1/4” Phillips
head screw (12)
S. 5/8” Pan head
wood screw (12)
W. 2 1/4 “ Allen
head bolt (16)
U. 3/8” Phillips
head screw (10)
X. Wood dowl (4)
Y. Cam bolt (3)
Z. Cam lock (3)
XX. 1 3/4” Allen
head bolt (4)
G
H
W
X
STEP 2A
A
Insert wood dowls (X) to the bottom side of each end
panel (A) as shown in the illustration below.
Use 2-1/4” Allen head bolts (W) to attach posts (G+H)
to each end panel (A).
STEP 2B
S
E
G & H
