Contents
Preparation . . . . ..... ... ... . . . . . . . . . . .... . . . . 2
Hardware Contents . . . . . . . .... . . . . . .... ... . . . . 2
Package Contents . ... .... ... . . . .... .... ... . . . 3
Umbrella Assembly . . .... .... . . . . .... ... ... . .4-6
Umbrella Operation . . .... ... ... ... . . . . . . . . . . .6-7
Warranty . . . . . . . ..... ... ... . . . . . . . . ...... . . . 8
Care and Maintenance . . .... .... ... . . . . ...... . . 8
Warnings and Cautions . . .... ... . . . . . .... .... . . 8
Replacement Parts . . .... .... . . . . .... ... ... . . . 9
Preparation
CAUTION: Do not use sharp tools to remove the protective material, as it may
damage the product. Be careful not to throw away small parts such as bolts, wash-
ers, etc., that may be wrapped in the protective materials.
Before assembling make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product. Contact our customer service representative for
assembly assistance or questions toll free at 1-855-880-7205.
Tools required for Assembly: Open end wrench or adjustable wrench (not included)
Phillips-head screw driver (not included)
Hardware Contents
GG
HH KK E
Part Description Quantity
GG Hex Bolt (M10-1.5x20 A2-70) 4
HH Hex Bolt (M10-1.5x25 A2-70) 9
KK Washer (M10 A2-70) 13
E Hex Wrench 1
To Next Page
