Backyard Discovery 55006 - Page 45

STEP 14
ATTACH M1 BOARD TO E2 BOARDS AS SHOWN.
ATTACH M18 PICKETS TO M1 BOARD AND K5 BOARD USING SPACING AS SHOWN
2 11/16"
(5 SPCS)
M1
M18
E2
E2
K5
SCREW PFH 8x1 1/8
(16 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
LAG SCREW
WH 5/16x2
(2)
WASHER
LOCK EXT
8x19
(2)
M1 - PICKET RAIL - W103760
5/8"x3 3/8"x30" (16x86x762)
(1)
M18 - PICKET - W103761
5/8"x3 3/8"x18 7/8" (16x86x480)
(4)
SCREW PFH
8x1 1/8
(16)
