Backyard Discovery 55006 - Tarp Installation

STEP 20
CENTER HY TARP OVER M4 TARP TOP SUPPORT AND ATTACH USING (4) 1/2" TAPPING
SCREWS, AS SHOWN.
NEXT, DRAPE HY TARP EVENLY OVER (2) M3 TARP SUPPORTS AND WRAP UNDERNEATH
AND UP THE BACK SIDE OF M3 SUPPORT APPROXIMATELY 1-13/16" FROM THE TOP AND
ATTACH USING (8) 1/2" TAPPING SCREWS, AS SHOWN.
HY - TARP 1522x2119 - A100062
1/32"x59 7/8"x83 3/8" (.4x1522x2119)
(1)
SCREW
TAPPING
8x1/2
(12)
SCREW TAPPING 8x1/2
(12 PLCS)
